Advanced Bag Filtration Systems
Rillway Technology designs and supplies heavy-duty bag filtration systems tailored to your specific process requirements. From compact single-bag vessels for batch processing to multi-bag duplex skids for continuous operations, our engineering expertise ensures maximum contaminant removal, low pressure drop, and reliable operation. We don’t just sell hardware—we optimize your fluid purity.
Fluid Diagnostics & Sizing
We analyze your process fluid properties—including flow rate, temperature, viscosity, and chemical compatibility—to precise-size the optimal housing and filter bag combination.
Custom Engineering Design
Every industrial system is engineered to fit your existing piping footprint. We provide comprehensive 2D/3D CAD drawings for approval before production begins.
Stringent Quality Compliance
Our separation systems are manufactured in compliance with international standards, offering SS304, SS316, or SS316L materials with full CE and ISO 9001 certification ready.
System Specifications & Configurations
| Feature / Parameter | Standard Options (Fully Customizable) |
|---|---|
| System Types | Single-Bag Vessels, Multi-Bag Housings, Duplex Skids |
| Housing Materials | Stainless Steel 304, 316, 316L, Carbon Steel |
| Bag Sizes Supported | Size #1, Size #2, Size #3, Size #4 |
| Max. Operating Pressure | 10 Bar (145 Psi) / 20 Bar (290 Psi) / Custom High Pressure |
| Max. Temperature Range | Up to 150°C (subject to O-ring & bag material) |
| Connection Types | ANSI / DIN / JIS Flanges, NPT / BSPT Thread, Tri-Clamp |
| Sealing O-Rings | EPDM, Viton, PTFE Encapsulated, Buna-N |
| Surface Finishing | Glass Bead Blasted / Mechanical Polish / Electro-polished |
Engineered for Demanding Industries
Water Treatment Systems
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.
Chemical & Petrochemical
Filtration of solvents, polymers, resins, acids, alkalis, and process chemicals.
Food & Beverage Processes
Pre-filtration for juices, edible oils, syrups, and FDA-compliant ingredient water.
Paints, Inks & Coatings
Fine filtration to remove agglomerates and ensure smooth surface finishes.
Get a Free Technical Sizing & Recommendation
Are you struggling with low filtration efficiency, frequent bag change-outs, or fluid bypass issues? Let Rillway’s technical team troubleshoot it for you.Send your fluid samples or process parameters to our engineers. We provide free laboratory analysis and custom equipment sizing to guarantee your flow rate and purity goals are met.
